Product Features
1.The discharge flange can be positioned at 8 directions with 45° spacing. Impeller options include different blade quantities: A (5 blades), B (4 blades), C (3 blades), D (2 blades), E (1 blade), F (6 blades), G (7 blades), etc.
2.Support structure: center-supported for horizontal model.
3.Optimized hydraulic design ensures high efficiency and minimal component wear.
4.Two shaft seal selections: packing seal and mechanical seal for reliable leak-free performance.
5.Wetted parts are manufactured from premium wear and corrosion resistant materials.
6.Suitable for seawater ash disposal, with outstanding resistance against corrosion from seawater, brine and salt fog.
Main Application
The ZJ type centrifugal slurry pump supports series and parallel connection, extensively serving power, metallurgy, coal washing, construction, chemical and filter press feeding systems.
It conveys abrasive slurries including mineral concentrate/tailings, power plant slag, coal slurry, dense-medium coal separation and shore sand.
Model Designation
For example:
Model: 200 ZJ-I-A-70
200 – Discharge diameter (mm)
ZJ – Slurry pump
I / Ⅱ – Single-stage / Two-stage pump
A – Impeller blade configuration
70 – Impeller diameter (mm)
Structure Diagram
