Product Features
- Adopts heavy-duty through-bolt structure and fully ductile iron lined casing, featuring high structural strength, durability and long service life.
- Equipped with large-diameter low-speed impellers and large open flow passages, which reduce internal flow velocity, minimize component wear, improve operating efficiency and lower total operating costs.
- Unique impeller structure is specially customized for complex and harsh froth conveying conditions.
- Configured with thick bolt-in metal and elastomer liners with excellent corrosion and abrasion resistance; liners are replaceable and interchangeable to reduce maintenance costs and extend pump service life.
- Optimized minimal shaft and impeller overhang design reduces shaft deflection and greatly prolongs packing service life.
- Adopts cartridge-style bearing assembly, enabling convenient and clean maintenance without pump disassembly, avoiding production downtime and extending bearing service life.
- Matches multiple centrifugal seal modes including full flush, low flow and dry running, which saves water resources and reduces operating expenses.
Main Application
Widely applied in metallurgy, mining, coal, chemical engineering and other industrial fields. It is specially suitable for conveying viscous, frothy, abrasive and corrosive slurries generated in mineral processing and oil sand extraction, and is the preferred equipment for various flotation process systems.
Structure Diagram
